Structure Characteristics:
QNS series submersible sand pump is specially designed for pumping in harsh environment, sites containing solids and other abrasive material. Each component fully reflects the design concepts of high durability, reliability and ease of maintenance. Each QNS submersible sand pump is adopted with F Class insulated 4-pole motor, high wear-resistant mechanical seal and heavy-duty semi-open high wear-resistant alloy impeller. There is an agitator in the lower part of this pump. The sediment at the bottom of water will be stirred into suspension form and then be sucked into the inlet to be discharged completely.
Application:
Underwater sand extraction, cleaning the bottom of the pond, cleaning the sedimentation tank Construction silt water drainage, mine surface drainage Industrial mining enterprises pumping sewage water containing quartz sand, slime, slage and other abrasive materials
Specification:
Insulation class : F
Protection class : IP68
Water temperature : up to 40°C
PH : 6 to 10
Density of liquid : up to 1.3g/cm³
Power supply : three phase 380V ± 10%, 50Hz
three phase 380V ± 10%, 60Hz
Capacity : up to 600m³/h
Head : up to 57m
Maximum immersion depth : 15m
Cable Legth : 8m
